Battery knowledge, made clear

Answers for better battery decisions.

Explore practical guidance on LiFePO4 batteries, inverter compatibility, system sizing, installation, shipping and after-sales support.

4Categories 61Expert answers
01

EU Warehouse & Shipping

10 questions
A
We work with freight forwarders we have cooperated with for many years and provide insurance for the carriage of goods.
If you have a preferred logistics provider or other special requirements, let us know and we will do our best to accommodate them.
A
Yes. For addresses the EU warehouse cannot ship to directly, we can send the goods to our forwarding partner in Germany, who arranges onward transport to Switzerland or other nearby countries.
Please contact our support team and we will recommend the forwarding address and the best solution for your order.
A
Cells are packed in cartons with anti-static protection, four-corner protection and shock-proof materials.
Standard packages ship without wooden pallets; if you need pallets or wooden boxes we can add them, but the corresponding freight will increase.
A
Truck delivery is palletized and arrives in one go: for example, 160 cells are shipped on two pallets.
Railway transport is cheaper, but the goods are delivered in several separate batches, so it suits customers who are not in a hurry to receive their solar battery order.
A
Yes. You will receive a tracking number by email once your order ships, which you can use to follow the shipment on the carrier's website.
If you have not received your tracking number, please contact our support team.
A
No. All prices are final door-to-door prices under DDP terms - the price shown on your invoice page is what you pay, with no extra cost and no additional taxes.
This applies to every solar battery storage order shipped from our EU warehouse to your address.
A
Orders are normally shipped within 7-15 working days after payment.
For a 48V lithium battery or a complete home battery backup system, delivery from our EU warehouse takes only a few extra days - no long sea freight wait.
A
LiFePo4 grade B cells are made from the same raw material as LiFePo4 grade A cells, with strict quality control procedures. Grade B cells have not been used yet, and some may have defects.
A
LiFePo4 grade B cells are made from the same raw material as LiFePo4 grade A cells, with strict quality control procedures. Grade B cells have not been used yet, and some may have defects.
A
LiFePo4 grade B cells are made from the same raw material as LiFePo4 grade A cells, with strict quality control procedures. Grade B cells have not been used yet, and some may have defects.
02

Product Specifications & Compatibility

29 questions
A
PowerThor 5000 uses a JK-Inverter BMS with CAN configured for Victron Energy by default and RS485 configured for Growatt by default, plus Bluetooth for local commissioning. Always confirm the exact inverter model, cable pinout, protocol selection and firmware because a matching connector alone does not establish compatibility.
A
PowerHarp 32 provides 32.15kWh nominal energy and 15.36kW continuous output, with a 20.5kW peak rating under the specified current and duration limits. Its 51.2V 628Ah architecture uses a 300A BMS, so cable sizing, isolation and fault protection must be engineered for the full system current.
A
Both provide approximately 16.07kWh from a 51.2V 314Ah LiFePO4 pack, but their installation formats differ. PowerHarp 16 is an integrated floor-standing indoor cabinet, while PowerFable 16 uses a serviceable 19-inch 6U rack format that can be installed only in its approved rack, stacking or caster configuration.
A
Confirm that the wall structure can support the battery and that the indoor location meets the required environmental limits, clearances and service access. The installer must also verify compatible inverter settings, cable routing, isolation and overcurrent protection before commissioning the 51.2V battery.
A
PowerFable 18 combines 18.23kWh of nominal energy with up to 8.7kW continuous output from a 51.2V 356Ah LiFePO4 pack. The kWh figure relates to stored energy and potential runtime, while the kW figure limits how much power the battery can deliver at one time.
A
PowerFable 16 is a 51.2V battery with CAN and RS485 communication for supported 48V-class inverter systems. Compatibility depends on the exact inverter model, communication protocol and firmware, so confirm the approved profile and current settings before installation.
A
PowerCornet 5 supports up to 16 parallel units for 81.92kWh of combined nominal capacity. A multi-battery rack requires approved BMS communication, balanced cable resistance, correctly rated busbars and overcurrent protection; do not place heavy batteries directly on one another unless an approved mounting system supports the configuration.
A
IP65 indicates that the PowerCarol 16 enclosure is protected against dust ingress and water jets under the rating conditions. It does not permit submersion or unrestricted exposure, so the installation must still follow the specified orientation, temperature limits, clearances, drainage and maintenance requirements.
A
LiFePO4 batteries have a relatively low self-discharge rate, which helps maintain stored energy over extended periods.
Even so, avoid leaving a battery at very low state of charge for a long time - deep self-discharge to 10V or below can permanently damage the cells.
A
LiFePO4 chemistry offers high thermal and chemical stability, a lower risk of thermal runaway, longer cycle life and lower cost than many other lithium-ion chemistries.
A single LiFePO4 cell has a nominal voltage of about 3.2V (versus 3.6-3.7V for other lithium-ion cells), and LiFePO4 batteries are widely used in solar energy storage, electric vehicles, power tools and electric bikes.
A
Yes, we can provide MSDS (Material Safety Data Sheet) documents for our cells.
Contact our support team and we will send the MSDS together with any test reports you need.
A
The exact maximum charging current is stated in each product's specification sheet - for example, 20P/10P configurations correspond to 200A/100A discharge current.
Exceeding the specified charge current may affect battery life, so always follow the specification for your solar battery.
A
JK displays are compatible with all JK BMS models, and no DC-DC converter is needed - JK has already handled this in the display wiring harness.
JK BMS itself has no WiFi; our PC-series BMS with 2A active balancing is available with WiFi, and a separate 4A active balancer can be added to either system.
A
Our cells use high-strength M6 studs (6 mm diameter) with a torque of 8 N.m.
Tighten the screws with additional wrist force, and note that the compression plate specification requires 300 kg of force.
A
Yes. The price of a pack includes all the cables needed for installation, and we provide a cable to connect the inverter with the battery.
For DIY cell orders, welded studs, flexible busbars and bolts are included, and buying cells also gets you a free flexible connecting piece.
A
Yes. Without a communication port you can set up the inverter manually: max charge voltage 55.2V, max charge current 150A, max discharge current 200A.
In lithium mode the battery communicates via CAN or RS485; in lead-acid mode no communication is needed - just set the parameters above.
A
Our batteries work with most mainstream inverters, including Victron, Deye and Goodwe (for example the Goodwe GW5048D-ES).
They cannot connect to Huawei or Sungrow inverters. If in doubt, send us your inverter model and we will confirm compatibility.
A
No. Battery packs with different capacities must not be connected in parallel.
The same applies to cells of different capacities or versions - for example, EVE 280Ah V1 must not be combined with EVE 280Ah V3 or EVE 314 cells.
A
No. Different cell types have different properties and characteristics, and mixing them affects the service life of the cells and the operation of the equipment, and may even create potential safety hazards.
Always build a battery pack from cells of the same model, batch and grade.
A
HSEV cells come with full factory test data readable from the QR code - including production date, capacity, voltage and internal resistance - and cost around 20% more than LSEV.
LSEV cells are professionally retested and matched before shipment and work fine for home energy storage, though they are not recommended for high-performance electric vehicles.
A
Level 1 (HSEV): EV-grade cells tested under the official test protocol, with intact QR code, real capacity, internal resistance and voltage - the highest quality level, used mostly in automotive industries.
Level 2 (LSEV): brand-new cells that did not pass the manufacturer's strict EV-grade test, retested and matched in capacity, voltage and internal resistance - they work fine for home energy storage.
Level 3 (ESS): brand-new cells matched in voltage and internal resistance only, with lower capacity consistency than LSEV.
A
Capacity degradation of our LiFePO4 batteries is approximately 2-4% per year under normal use.
Following the recommended charge voltage and avoiding long periods at very low state of charge keeps degradation at the lower end of this range.
A
EVE 280Ah LiFePO4 cells have been rigorously tested and deliver a cycle life of up to 8,000 cycles.
As with any lithium battery, the actual service life also depends on temperature, charge voltage and depth of discharge in your solar battery system.
A
The official cycle life rating for the cell is 3,000 cycles at 0.5C/0.5C, yet the manufacturer provides a 6,000-cycle figure for the pack.
The reason is that real-world use is never at 100% depth of discharge and not always at 1C charge and discharge, so the actual service life of your solar battery is typically longer than the laboratory rating.
A
Our rack and powerwall batteries use 102Ah LiFePO4 cells rather than the 105Ah version, and the depth of discharge (DoD) is not limited by default.
With the communication box, the DoD can be set freely by the customer. At 100% DoD the packs deliver 3,000-3,500 cycles, with a maximum of 4,000 cycles.
A
LiFePo4 grade B cells are made from the same raw material as LiFePo4 grade A cells, with strict quality control procedures. Grade B cells have not been used yet, and some may have defects.
A
LiFePo4 grade B cells are made from the same raw material as LiFePo4 grade A cells, with strict quality control procedures. Grade B cells have not been used yet, and some may have defects.
A
LiFePo4 grade B cells are made from the same raw material as LiFePo4 grade A cells, with strict quality control procedures. Grade B cells have not been used yet, and some may have defects.
A
LiFePo4 grade B cells are made from the same raw material as LiFePo4 grade A cells, with strict quality control procedures. Grade B cells have not been used yet, and some may have defects.
03

Home Energy Storage & Off-Grid Applications

10 questions
A
Each PowerThor 5000 module provides 5.12kWh nominal energy, so the required quantity depends on essential-load kWh, desired backup time and reserve for conversion losses and operating limits. Also verify the inverter battery-current limit and system protection; the product supports 16 parallel units as standard and up to 32 with supported firmware.
A
PowerHarp 32 can suit large residential, workshop and light-commercial energy profiles when 32.15kWh of storage and 15.36kW continuous output match the measured load. Use interval consumption data where possible and have a qualified designer plan the inverter, protection, conductors and any parallel battery bank.
A
PowerHarp 16 is designed for residential backup and provides 16.07kWh nominal energy, 7.68kW continuous output and 10.2kW peak output under the stated conditions. Whether it can support the entire home depends on the selected circuits, starting loads, inverter, transfer equipment and required backup duration.
A
PowerGlee 5 can be a practical starting point for selected loads such as refrigeration, lighting, communications and essential outlets. Calculate watt-hours for the desired backup period and check simultaneous demand against its 5.12kW continuous output; additional modules may be needed for longer runtime or more circuits.
A
An 18kWh battery is worth considering when measured household consumption, a longer backup target or solar self-consumption requires more storage than a typical 5kWh module. Size the system from real load data and verify that the 8.7kW continuous output, inverter rating and protection design cover simultaneous demand.
A
PowerFable 16 stores 16.07kWh of nominal energy, but actual backup time depends on the connected load, inverter efficiency, configured operating limits and site conditions. Add the wattage of the essential circuits, multiply each load by its expected running time and compare the total kWh with the battery capacity.
A
One PowerCornet 5 provides 5.12kWh nominal energy and 5.12kW continuous output, which may suit a compact essential-load or cabin system. Off-grid sizing must also account for daily consumption, days of autonomy, seasonal solar production, inverter losses and the required charging source, so some systems will need multiple modules.
A
Yes, PowerCarol 16 is an IP65 indoor/outdoor LiFePO4 battery with 16.08kWh nominal energy and 7.68kW continuous output. Choose a stable, serviceable and specification-compliant location, then plan weather-appropriate cable routing, isolation, overcurrent protection and inverter communication.
A
We do not recommend stacking batteries directly on top of each other because of their heavy weight - use a rack to hold them instead.
Please note we do not sell racks ourselves, so the rack would need to be sourced locally.
A
Yes, but only to power household appliances on board - they cannot be used as the boat's propulsion system.
The cell type and BMS in our storage batteries differ from those required for traction and power applications such as small vehicles.
04

Warranty, Technical Support & Returns

12 questions
A
An interrupted firmware update can cause abnormal voltage, current and SOC readings.
Simply run the firmware update again and make sure it completes fully without interruption - the readings will return to normal.
A
Large SOC differences between parallel battery packs usually mean the packs have not been fully charged for too long.
Charge all the batteries to 100% promptly and keep doing this regularly - especially in winter when there is little PV charging, configure the inverter to charge the batteries from AC when solar power is insufficient.
A
This is a parameter setting issue: the SOC-100% voltage threshold is set too high relative to the actual cell voltage.
Adjust the SOC-100% voltage to 3.41V per cell in the BMS software, then run a full charge - the battery will reach 100%.
A
First check the inverter settings: make sure the lithium battery mode is selected for the battery port, and set the start-of-charge SOC where you want it (the default can be as high as 30% and can be lowered to 15% in the inverter settings).
In winter, charging from the grid may be blocked by low-temperature protection - if the ambient temperature is below the protection value (default 5 degrees C), adjust the low-temperature protection setting in the BMS.
A
SOC errors usually appear when the battery has not been fully charged for a long time, causing voltage and SOC to drift apart - charge the battery to 100% at least once a month.
If the SOC stays stuck at a partial value while the voltage is already near full, update the BMS firmware; in the BMS software, the SOC-100% voltage must be set 0.04V below the cell RCV voltage.
A
When a battery is not fully charged for several consecutive days, the BMS enters protection mode and sets the discharge current limit (DCL) to 0.
Set the minimum SOC alarm to 5% in the BMS software and charge the battery to 100% regularly - the protection is released after a full charge.
A
Yes. Our professional technical support team can help with battery use, maintenance and troubleshooting for your home battery backup system.
We also provide installation videos for DIY kits and firmware updates when needed.
A
We accept PayPal and credit card (4.4% extra processing cost), Alibaba Trade Assurance (3% extra cost) and TT bank/wire transfer (no extra cost).
The additional fee on card payments simply covers secure payment processing and applicable service charges from our payment processors.
A
If your order has not yet been shipped, we can modify or cancel it - please contact us as soon as possible.
Once an order has been shipped it cannot be cancelled or modified straight away, but you can return it in accordance with our returns policy.
A
We are sorry for the inconvenience - we will send you a replacement cell.
Please contact us with photos as soon as the goods arrive so we can process the replacement quickly.
A
If any quality problem occurs during the warranty period, we are responsible for free replacement or repair.
Simply contact our technical support team with your order details and a description of the issue, and we will arrange the solution.
A
We offer a five-year warranty on cells and standard batteries, and ten years on Premium batteries.
For DIY kits, the cells carry a 10-year warranty while the BMS is covered for 1 year. All warranties include comprehensive after-sales service with technical support and replacement.
